FLIR AX8 Specifications
IMAGING & OPTICAL DATA
IR Resolution 80x60 pixels
Thermal Sensitivity / NETD <0.10°C @ +30°C (+86°F) / 100mK
Field of View (FOV) 48° x 37°
Focus Fixed
DETECTOR DATA
Detector Type Focal Plane Array (FPA) Uncooled Microbolometer
Spectral Range 7.3-13µm
VISUAL CAMERA
Built-in Digtal Camera 640x480
Digital Camera FOV Adapts to the IR lens
Sensitivity Minimum 10 Lux without illuminator
MEASUREMENT
Object Temperature Range -10°C to +150°C (14°F to 302°F)
Accuracy +/-2°C (+/-3.6°F) or +/-2% of reading (+10 to +100C@+10 to +35amb)
MEASUREMENT ANALYSIS
Spotmeter 6
Area 6 Boxes with max. / min. / average
Automatic Hot / Cold Detection Max / Min temperature value and position shown within box
Measurement Presets Yes
Atmospheric Transmission Correction Automatic, based on inputs for distance, atmospheric temperature and relative humidity
Optics Transmission Correction Automatic, based on signals from internal sensors
Emissivity Corrections Variable from 0.01 to 1.0
Reflected Apparent Temperature Correction Automatic, based on input of reflected temperature
External Optics / Windows Correction Automatic, based on input of optics / window transmission and temperature
Measurement Corrections Global Object Parameters
ALARM
Alarm Functions Automatic alarms on any selected measurement function. A maximum of 5 alarms can be set
Alarm Output Digital Out, store image, file sending (ftp), email (smtp), notification
SET-UP
Color Palettes Color palettes (BW, BW inv, Iron, Rain)
Set-up Commands Data / Time, Temperature °C/°F
Web Interface Yes
STORAGE OF IMAGES
Storage Media Built-in memory for internal storage
Image Storage Mode IR, Visual, MSX
File Formats Jpeg + FFF
ETHERNET
Ethernet Control, result and image
Ethernet Type 100 Mbps
Ethernet Standard IEEE 802.3
Ethernet Connector Type M12 8-pin X-coded
Ethernet Video Streaming Yes
Ethernet Power Power over Ehternet, PoE IEEE 802.3as class 0
Ethernet Protocols Ehternet/IP, Modbus TCP, TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, SFTP, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour)
MARINE ELECTRONICS INTERFACE
Multifunction Displays Network compatible with Raymarine LightHouse II multifunction displays
IMAGE STREAMING
Image Streaming Formats Motion JPEG, MPEG, H.264
Image Streaming Resolution 640x480
Image Modes Thermal, Visual, MSX (IR-image with enhanced detail presentation)
Automatic Image Adjustment Continuous
POWER SYSTEM (POE Injector)
External Power Operations 12/24VDC, 2W continuously / 3.1W absolute max
External Power Connector Screw Connection (12V/0V/Chassis)
Voltage Allowed Range 9-36VDC
ENVIRONMENT DATA
Operating Temperature Range 0°C to +50°C (32°F to +122°F)
Storage Temperature Range –40°C to +70°C (–40°F to +158°F) IEC 68-2-1 and IEC 68-2-2
Humidity (Operating and Storage) IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C (+77°F to +104°F)/ 2 cycles
EMC EN 61000-6-2:2001 (Immunity) | EN 61000-6-3:2001 (Emission) | FCC 47 CFR Part 15 Class B (Emission) | EN 60945:2002 | EN60945 (Electromagnetic Compliance)
Encapsulation IP67 (IEC 60529)
Bump 25 g (IEC 60068-2-29)
Vibration 2 g (IEC 60068-2-6)
EN 60945:2002
Ignition Protection EN 28845:1993
PHYSICAL DATA
Camera size (L × W × H) 54 × 25 × 79 mm (2.1 x 1 x 3.1 in.) w/o connectors
54 × 25 × 95 mm (2.1 x 1 x 3.7 in.) w/ connectors
SHIPPING INFORMATION
Packaging Infrared camera with lens, printed documentation, user documentation CD-ROM, cooling/mounting plate, POE injector, Camera PoE Cable, Raymarine RayNet Ethernet cable
